MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf

The MOTIC Microscope BA310E Binocular is a versatile and high-performance microscope designed for laboratory and educational use. Featuring a binocular tubus with the Siedentopf design, it ensures comfortable and precise viewing with adjustable eyepieces for users of different heights. The N-WF10X/20mm eyepiece provides clear and accurate imaging, while the ergonomic design reduces eye strain during extended use. This microscope is ideal for routine laboratory applications and educational settings where reliable, high-quality optics are required.

Key Features:

• Brand: MOTIC
• Optical System: Infinity Optics [CCIS]
• Eyepiece Design: Observation Tube Siedentopf Type, Binocular - / Phototube 30°, F.N. 20
• Interpupillary Distance: 48-75 mm
• Eyepieces: High-Eyepoint N-WF 10x/20 mm with dioptre adjustment on both eyepieces and rubber eyecups
• Nosepiece: Reversed quintuple revolving nosepiece
• Objectives: CCIS EC Plan 4x, 10x, 40x-S, 100x-S-Oil
• Mechanical Stage: Built-in low position coaxial, rackless mechanical stage (right hand control)
• Condenser: Focusable Abbe condenser N.A. 0.90/1.25 with iris diaphragm and slot
• Optical Control: Koehler illumination 3 W LED with intensity control
• Power: Universal power supply 100-240 V

Scope of Supply:

• Immersion oil (5 ml)
• Power cord
• Allen hexagonal key
• Thumb screw
• Vinyl dust cover

The MOTIC Microscope BA310E Binocular is designed to deliver excellent optical performance with an ergonomic, user-friendly design, making it the perfect choice for educational institutions and laboratories alike.

Frequently Asked Questions

1. What is the MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf used for?

It is a versatile and high-performance microscope designed for laboratory and educational use. Featuring a binocular tubus with the Siedentopf design, it ensures comfortable and precise viewing with adjustable eyepieces for users of different heights. The N-WF10X/20mm eyepiece provides clear and accurate imaging, while the ergonomic design reduces eye strain during extended use. This microscope is ideal for routine laboratory applications and educational settings where reliable, high-quality optics are required.

2. Is the MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf suitable for laboratory and educational use?

Yes. It is designed for laboratory and educational use, and offers an interpupillary distance of 48-75 mm and 6 V/30 W HAL illumination available on option to support this kind of work.

3. What interpupillary distance does the MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf have?

It has an interpupillary distance of 48-75 mm and 6 V/30 W HAL illumination available on option, and is supplied under manufacturer part number 1100000000000.

4. What additional detail and additional detail does the MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf offer?

It offers infinity Optics [CCIS], observation Tube Siedentopf Type, Binocular - / Phototube 30°, F.N. 20, high-Eyepoint N-WF 10x/20 mm with dioptre adjustment on both eyepieces and rubber eyecups and reversed quintuple revolving nosepiece.

5. How does the MOTIC Microscope BA310E Binocular N-WF10X/20mm, Binocular Tubus, Type Siedentopf compare with the Kern & Sohn Compound Microscope OBT 106 Binocular, Achromat 4/10/40/100 WF10x18; 1W LED from Kern & Sohn?

For laboratory and educational use, the Motic model is the better choice, offering an interpupillary distance of 48-75 mm and 6 V/30 W HAL illumination available on option. The Kern & Sohn model offers a magnification of 4x, 10x, 40x, 100x (Achromat objectives) and an illumination of 1W LED for bright and uniform lighting as an alternative, while the Motic model's infinity Optics [CCIS] and observation Tube Siedentopf Type, Binocular - / Phototube 30°, F.N. 20 help make it a strong fit for laboratory and educational use.
