Representative image only
Nabertherm Horiz.High-Temper.Tube Furnace RHTH 80/300/16/P570 Tmax 1600°C, Including Working Tube C 799 and 2 Fibre Plugs 70x530 mm Iø x L
Sold by: John Morris Scientific NZ
Available Soon
Part #: 9.764 561Manufacturer #: RH282V62AN
Estimated shipping time:Contact us via live chat or via contact us page
Product overview
The Nabertherm Horiz.High-Temper.Tube Furnace RHTH 80/300/16/P570 Tmax 1600°C, Including Working Tube C 799 and 2 Fibre Plugs 70x530 mm Iø x L is designed for horizontal or vertical laboratory heat treatment processes with 1600°C and 70x530 mm. This Nabertherm tube furnace supports reliable laboratory and scientific workflows.
Key Features:
- Brand: Nabertherm
- Product Type: Tube Furnace
- Temperature Range: 1600°C
- Dimensions: 70x530 mm
- Design: The high-temperature tube furnaces are available in either horizontal (type RHTH) or vertical (type RHTV) designs
- Application: Horizontal or vertical laboratory heat treatment processes
This Nabertherm tube furnace is suitable for laboratories requiring accurate specifications, dependable handling, and consistent day-to-day use.
Product Specifications
- HS Code #85141980
- Depth550 mm
- Dimensions (WxDxH)620 x 550 x 640 mm
- Power supply frequency50/60 Hz
- Height640 mm
- Length tube530 mm
- Length tube heated300 mm
- Max. ext. tube Ø80 mm
- Max. temperature1600 °C
- Max. voltage480 V
- Min. voltage380 V
- Power supply380 ... 480 V, 50/60 Hz
- Rated capacity9000 W
- TypeRHTH 80/300/16/P570
- Type of auxiliary energyMains connection
- UNSPSC40101805
- Weight90 kg
- Width620 mm
Downloads
- Nabertherm High-Temperature Tube Furnaces Catalogue ExcerptDownload
